DOBOT Robot Vision Kit provides an essential software and hardware platform based on visual development. With the advantages of rich functions, stable performance, and convenient operation, it perfectly meets the needs of optical applications, including visual positioning, measurement, detection, and recognition. DOBOT Robot Vision Kit obtains a clear and intuitive design, making it easy to operate.
| HD Color Industrial Camera | |
| Sensor Size | 1/2.5"CMOS |
| Sensor Type | AR0521 |
| Effective Pixel | 5 Million |
| Hue | Color |
| Pixel Size | 2.2×2.2 um |
| Frame Rate / Resolution | 31 @2592×1944 |
| SNR | >40 dB |
| Dynamic range | >60 dB |
| Shutter Type | Curtain Exposure |
| Time of exposure | Bayer：16μs-1sec Other Format：28μs-1sec |
| Exposure control | Auto/Manual |
| Size | 29 mm × 29 mm × 30 mm |
| Data Interface | USB 3.0 |
| Data Format | Mono 8/10/12，Bayer GR 8/10/10p/12/12p，YUV422_YUYV_Packed，YUV422_Packed，RGB8 |
| Lens Mount | C-Mount |
| Six Megapixel 12mm Fixed Focus Lens | ||
| Focus | 12 mm | |
| Maximum Image Size | 1/1.8＂(φ9 mm) | |
| Aperture | F2.8 - F16 | |
| Control | Aperture | Manual |
| Focus Point | Manual | |
| Visual Angle | D | 41.2° |
| H | 1/1.8＂ 34.4° | |
| V | 23.4° | |
| Optical Distortion | -0.38% | |
| Flange Back Focus | >17.526 mm | |
| Recent Shooting Distance | 0.06 m | |
| Mount | C-Mount | |
| Filter Thread | M27×0.5 | |
| Size | φ29×35.36 mm | |
| Luminous color | White |
| LED number | 48 LED |
| Illumination | 40000 lux |
| Wavelength | 455 – 457.5 nm |
| Operating distance | 35 – 110 mm |
| Size specification | Internal Diameter: 40mm, External Diameter: 70mm, Height: 25mm |
| Outer Diameter of Lamp Barrel | Max Φ39 mm |
| Weight | 0.48 KG |
